SECURE KVM EXTENDER

SKU FS-SKVM-11HD-E-KIT

FIBERBLOCKER GALVANIC SECURE KVM HDMI 1:1 EXTENDER

Isolated Channels: Ensures complete isolation of each computer or device connected to the KVM switch, preventing any data leakage between channels.

Unidirectional Data Flow: Employs hardware-based data diodes to enforce unidirectional data flow for video, USB, and audio signals, preventing unauthorized or accidental data transfers to connected devices.

High-Resolution Video: Up to 4k video resolutions via HDMI or DisplayPort, delivering clear and sharp display quality across all connected systems.

Matrix Switching: Allows any input to be routed to any monitor, enabling flexible and independent control of which source is displayed on each monitor. This enhances operational versatility and allows for customized viewing configurations.

Push Button Selection: Provides Facilitates easy device switching using physical push buttons for quick and reliable control.

Hotkey Functions: Offers fast switching between devices through  predefined keyboard shortcuts, streamlining workflow and enhancing efficiency.

Choose Configuration

FS-SKVM-11DP-E-KIT

SKUFS-SKVM-11DP-E-KIT

The Fiber BLOCKER KVM Extender family is designed for government, defense and other sensitive environments that require access to multiple computers from a common operator position while preserving separation between systems.

The family scales from a simple 1×1 extender to 2×2 and 4×2 dual-monitor configurations, allowing organizations to select the number of computers and displays required by the workstation.

Source-Side Transmitter (Tx)

Each source computer connects to its own transmitter unit using either HDMI or DisplayPort input.

Optical SFP+ Link

Each transmitter uses one SFP+ port to communicate with the receiver-side secure KVM.

Receiver-Side Secure KVM (Rx)

The receiver provides one or two HDMI display outputs plus keyboard/mouse connectivity via USB-A or PS/2.

One Tx per Optical Port

Each kit includes one transmitter per SFP+ port on the selected receiver.

SFP+
HDMI / DisplayPort Input
HDMI Output
USB-A / PS/2
1 / 2 / 4 Sources

1×1

1 source computer → 1 HDMI monitor output.

HDMI: FS-SKVM-11HD-E-KIT
DisplayPort: FS-SKVM-11DP-E-KIT

2×1

2 source computers → 1 HDMI monitor output.

HDMI: FS-SKVM-21HD-E-KIT
DisplayPort: FS-SKVM-21DP-E-KIT

2×2 Matrix

2 source computers → 2 HDMI monitor outputs.

HDMI: FS-SKVM-22HD-E-KIT
DisplayPort: FS-SKVM-22DP-E-KIT

4×1

4 source computers → 1 HDMI monitor output.

HDMI: FS-SKVM-41HD-E-KIT
DisplayPort: FS-SKVM-41DP-E-KIT

4×2 Matrix

4 source computers → 2 HDMI monitor outputs.

HDMI: FS-SKVM-42HD-E-KIT
DisplayPort: FS-SKVM-42DP-E-KIT

Configuration Matrix Switching Hotkey Push Button Read/Write EDID Dual Monitor
1×1 HDMI / DP No Yes No Yes No
2×1 HDMI / DP No Yes Yes Yes No
2×2 HDMI / DP Yes Yes Yes Yes Yes
4×1 HDMI / DP No Yes Yes Yes No
4×2 HDMI / DP Yes Yes Yes Yes Yes

Matrix Switching applies only to the dual-monitor 2×2 and 4×2 variants. Do not describe the 1×1, 2×1 or 4×1 kits as matrix switchers.

Receiver Model Type Video Output Optical Data Communication Keyboard / Mouse
1-source receiver 1 × HDMI Out 1 × SFP+ SM/MM 2 × USB-A + 2 × PS/2
2-source / 1-monitor receiver 1 × HDMI Out 2 × SFP+ SM/MM 2 × USB-A + 2 × PS/2
2-source / 2-monitor receiver 2 × HDMI Out 2 × SFP+ SM/MM 2 × USB-A + 2 × PS/2
4-source / 1-monitor receiver 1 × HDMI Out 4 × SFP+ SM/MM 2 × USB-A + 2 × PS/2
4-source / 2-monitor receiver 2 × HDMI Out 4 × SFP+ SM/MM 2 × USB-A + 2 × PS/2

Transmitter Units

Tx Type Video Input Optical Link Power
HDMI Transmitter 1 × HDMI In 1 × SFP+ 12 VDC power inlet; datasheet also lists USB-powered operation for transmitter unit
DisplayPort Transmitter 1 × DisplayPort In 1 × SFP+ 12 VDC power inlet; datasheet also lists USB-powered operation for transmitter unit

Power wording in the family datasheet combines “USB-Powered” and “12V DC” under transmitter/general power. Keep the public page at architecture level unless Product Engineering confirms the exact power behavior for each transmitter revision.

Parameter Published Specification
Video Resolution Up to 4K
HDCP Not supported
Maximum Power Consumption 5 W — all KVM models / transmitter unit
Operating Temperature 0°C to 50°C
Storage Temperature -20°C to 75°C
Operating Humidity Up to 90%, non-condensing
Color Black

Receiver Dimensions

Receiver Dimensions (H × W × D) Weight
FS-SKVM-11HD-RX / FS-SKVM-11DP-RX 29.9 × 143.7 × 97.6 mm 264 g
FS-SKVM-21HD-RX / FS-SKVM-21DP-RX 27.6 × 215 × 97.5 mm 392 g
FS-SKVM-22HD-RX / FS-SKVM-22DP-RX 27.6 × 215 × 97.5 mm 433 g
FS-SKVM-41HD-RX / FS-SKVM-41DP-RX 27.6 × 215 × 97.5 mm 433 g
FS-SKVM-42HD-RX / FS-SKVM-42DP-RX 27.6 × 215 × 97.5 mm 433 g

Transmitter Dimensions

Transmitter Dimensions (H × W × D) Weight
HDMI Tx 28.4 × 96.8 × 97.4 mm 189 g
DisplayPort Tx 28.4 × 96.8 × 97.4 mm 189 g

Each laptop or computer connects to its own Tx unit. The Tx units connect optically to the receiver/KVM switch over SFP+ links. The operator connects keyboard and mouse to the receiver and uses one or two HDMI monitors depending on the selected model.

Part Number Description
FS-SKVM-11HD-E-KIT 1 Tx unit with HDMI input, 1 HDMI monitor output
FS-SKVM-11DP-E-KIT 1 Tx unit with DisplayPort input, 1 HDMI monitor output
FS-SKVM-21HD-E-KIT 2 Tx units with HDMI input, 1 HDMI monitor output
FS-SKVM-21DP-E-KIT 2 Tx units with DisplayPort input, 1 HDMI monitor output
FS-SKVM-22HD-E-KIT 2 Tx units with HDMI input, 2 HDMI monitor outputs
FS-SKVM-22DP-E-KIT 2 Tx units with DisplayPort input, 2 HDMI monitor outputs
FS-SKVM-41HD-E-KIT 4 Tx units with HDMI input, 1 HDMI monitor output
FS-SKVM-41DP-E-KIT 4 Tx units with DisplayPort input, 1 HDMI monitor output
FS-SKVM-42HD-E-KIT 4 Tx units with HDMI input, 2 HDMI monitor outputs
FS-SKVM-42DP-E-KIT 4 Tx units with DisplayPort input, 2 HDMI monitor outputs

Optional Accessories

Part Number Description
FIM-HD2C-2M HDMI 2.0 cable, 2 m
FIM-CBL-DPM-DPM-1.8M DisplayPort male-to-male cable, 1.8 m
FIM-CBL-USBA-USBB-1.8M USB-A to USB-B cable, 1.8 m
Q-SFP+-10G-SR-300M SFP+ 10 Gbps multimode optical module, 850 nm, 300 m
FG9-9999UU00200 20 m optical cable with LC/UPC
FG9-9999UU00300 30 m optical cable with LC/UPC
FG9-9999UU01000 100 m optical cable with LC/UPC

The 300 m distance belongs to the listed optional SFP+ module. It should not be presented as the universal maximum distance for every possible optical configuration.

Send Fibernet the number of source computers, HDMI/DisplayPort interface, number of monitors, optical distance and switching workflow. We can help select the correct Fiber BLOCKER KVM Extender kit and optical accessories.
